Reverberation Chamber for Bjork's Cornucopia, New York City, New York

Designing an intimate acoustic reverb chamber for Bjork’s Cornucopia tour

Björk has designed an entirely new kind of stage production for her Cornucopia tour.

Combining elements of live theatre, immersive media, and musical ensemble, ­­­­­­­­­­­­Björk pushes the boundaries of the live concert experience. In her latest show, she sought to capture the intimacy of singing live in a small room, unaided by traditional stage amplification and audio processing. She commissioned Arup to design an acoustic reverberation chamber as part of the touring set — a unique approach to live stage performance that projects an encapsulated and solacing moment to a large-scale audience. The reverb chamber becomes both sanctuary and instrument, enabling Björk to sing in a naturally enveloping acoustic.

Our acoustic designers worked iteratively with Björk and her creative team, developing a form that achieves a lush and enveloping natural reverberation for the touring production. For the shape, materiality, and size of the chamber, Björk and her team worked with Shane Myrbeck, Wendy Lee, and Raj Patel, using the Arup SoundLab in their design process to develop and deliver the final form.

Based on previous experience with our SoundLab, Björk approached us for our ability to model and immersively simulate the experience of singing in the chamber. She challenged the Arup team to evaluate a wide variety of shapes and materials and relied on us to consider every implication of the chamber form: acoustics first, but also audience sightlines, weight, portability, and durability in a touring environment.

i would like to thank Arup for a divine collaboration, their acousticians helping me design my own private reverb chamber i can travel with. it has been a pleasure!

Björk_Volta copyright creative commons Björk

Designing a form driven by sound

Björk was inspired by small chapels, natural forms, and sound sculptures like Tvisöngur in Iceland for their lush reverberation and organic quality. Because this chamber would have to be portable for touring, however, we could not use the stone and masonry common to these precedents. To evaluate materials, we calibrated our modelling process to measurements of spaces of a similar size and shape, such as the Sound Column at the Palace of the Fine Arts in San Francisco, and the Integratron sound bath in the Mojave Desert. Once our modelling process was calibrated to these shapes, we were able to explore many new forms based on our library of materials.

Björk sketched many potential shapes, inspired by anything from orchids to the Sydney Opera House. She insisted, however, that the acoustic performance should be the main design driver of the form. As such our design process was highly collaborative and iterative, with the Arup team modelling many shapes for Björk to evaluate over headphones. Once we settled on a suite of final options, Björk and the production team met in London’s SoundLab to listen critically in our purpose-built 3D sound studio. The final design has an octagonal shape in plan to create strong reflections from many directions, with a vaulted ceiling inspired by medieval chapels, to create a diffuse and blended sound quality.

In designing an acoustic reverberation chamber for Björk’s Cornucopia tour, Arup modeled how sound would reflect and reverberate within several different shapes. Arup and Björk ultimately selected this vaulted shape.
To view this video, you must enable cookies.

Material matters

The material for the reverb chamber had to perform acoustically first and foremost, but also required portability, durability to last the tour, and visibility for audience sightlines. While our original assumption was that a clear acrylic would be preferred for its transparency, the team soon determined it would not meet the project acoustic requirements. The chamber is constructed with a wood frame coated in a thick reinforced plaster composite, a combination which both produces good sound and uses common building materials that can be repaired by production staff on tour.

Once our design was established, we issued documents for fabricators to use as their basis of design for bid. The chamber was built by Irma Studio in Iceland, a frequent set builder for Björk’s touring productions. The chamber was constructed months in advance of full ensemble rehearsals to allow enough time for Björk to experiment with its acoustic response and be comfortable performing inside before her residency began.

Björk is an inspiring collaborator — deeply creative and dedicated to exploring the outer limits of her work both musically and technically. She challenges her creative teams to work in the realm of the unknown and unprecedented, while balancing her whimsy with a remarkable depth of technical knowledge of even the most arcane aspects of her craft. ” Shane Myrbeck Shane Myrbeck Associate Principal

The first performances of Cornucopia will be presented as part of a residency at The Shed, a new cultural arts centre in New York’s Hudson Yards neighbourhood, from May 9–June 1.
